Open Cam Single Plate Middle Speed Paper Cup Machine with Ultrasonic Heater
Open Cam Single Plate Middle Speed Paper Cup Machine with Ultrasonic Heater

Open Cam Single Plate Middle Speed Paper Cup Machine with Ultrasonic Heater

MOQ: 1 Set
Price: Negotiate FOB Ningbo
Packaging Details: Wooden Case
Delivery Time: 35 days
MOQ: 1 Set
Price: Negotiate
Packaging Details: Export Standard Wooden Case
Delivery Time: 25 days
× 大图
Detail Information
Paper Weight:
140gsm-250 GSM
Paper Cup Size:
3 ~12OZ (30ml~330ml Mould Exchangeable) Max Cup Height To 115 MM, Max Cup Bottom Diameter 80MM
Speed:
65-75 Pcs/min
Color:
Blue Door White Frame
Output:
50/60HZ, 380V/220V
Model:
JBZ-ocs12
Power:
4.8KW
Working Air Source:
No Need Provide Air
Gross Weight:
1450Kg
Place of Origin
China
Brand Name
Mingyuan
Certification
CE, SGS
Model Number
JBZ-ocs12
High Light:

Single Plate Middle Speed Paper Cup Machine

,

Open Cam Paper Cup Making Machine

,

Paper Cup Machine With Ultrasonic Heater

Product Description

               Ultrasonic Heater Open Cam Single Plate Middle Speed Paper Cup Machine with ultrasonic

Model
JBZ-OCS12 Open Cam Single plate Middle Speed Paper Cup Machine
Cup Side Welding:
Copper heater
Paper Cup Size
3 ~12OZ (30ml~330ml Mould exchangeable) Max Cup height to 115 MM, Max Cup Bottom Diameter 80MM
Raw Material
Only one-side PE coated paper ( Popular for Hot drink cups )
Suitable Paper Weight
140gsm-250 GSM
Speed
65-75 pcs/min
Total Power
4.8KW
Power Source
50/60HZ, 380V/220V ( better use 380V, 3 Phase ) or special Power requirement.
Gross Weight
1450Kg
Machine Size(L * W * H)
2000*900*1600mm
Package Size(L * W * H)
2100*1000*1700mm
Working Air Source:
No need provide Air
Cup Bottom Knurling:
Heater Knurling (if use single PE coated paper)
Packing
Seaworthy Wooden Case
Cup Bottom Heating:
Heater Knurling



Open Cam Single Plate Middle Speed Paper Cup Machine with Ultrasonic Heater 0Open Cam Single Plate Middle Speed Paper Cup Machine with Ultrasonic Heater 1Open Cam Single Plate Middle Speed Paper Cup Machine with Ultrasonic Heater 2Open Cam Single Plate Middle Speed Paper Cup Machine with Ultrasonic Heater 3

Using famous brand motors, the quality of accessories is guaranteed
1 1 year warranty service.
2 Free replacement of parts within 1 year (free shipping).
3 Parts are provided free of charge within 2 years, but no free shipping.



Remote guidance, save your time
1 We provide Operation & Maintenance CD.
2 When there is a problem with the machine, please take a video of the problem and send it to us.
3 We will arrange professionals to help you deal with it through video or document tutorials.
Q1. Are you trading company or manufacturer?
A:we are one of the leading manufacturer of the paper cup machine, Plastic lid machine, paper plate machine etc paper product
machinery in China.
Q2. Do you have quality certificate?
A:we have got the ce certificate for our machine.
Q3. What's the delivery time?
A:Around 20~30 days, however, based on order.
Q4. where is your factory location?
A:we are locate in Henghe industrial zone, feiyun street, ruian city, zhejiang province, china. our nearest high way exit is
feiyun, our nearest train station is ruian station, our nearest airport is wenzhou airport.
Q5.How does your factory do regarding quality control?
A:Quality is priority. Our Factory always attach great importance to quality controlling from the very beginning to the very end:
1).Skilful workers care every details in handling the producing and packing processes;
2).Quality Control Department specially responsible for quality checking in each process.
Q6. What terms of payment you usually use?
A:T/T 30% deposit and 70% before machine loading, Western Union, L/C at sight.
